Application
CJX2-D series AC contactor is suitable for using in the circuits up to the rated voltage 660V, AC50 or 60Hz, rated current up to 95A, for making, breaking, frequently starting & controlling the AC motor. Combined with the auxiliary contact block, time delay & machine –interlinking device etc, it becomes the time delay contactor, reversible contactor, star-delta starter, and with the thermal relay, it can be combined into the electromagnetic starter.
Specification
|
Type |
Rated voltage(V) |
Conventional current(A) |
Rated current(A) |
Control power(kw) |
No .of contacts |
Installation Method |
||||
|
220V |
380V |
415V |
440V |
660V |
||||||
|
LC1-0910 |
660 |
20 |
9 |
2.2 |
4 |
4 |
4 |
5.5 |
3P+1NO |
1with two screws rail |
|
LC1-0901 |
660 |
3P+1NC |
||||||||
|
LC1-1210 |
660 |
25 |
12 |
3 |
5.5 |
5.5 |
5.5 |
7.5 |
3P+1NO |
|
|
LC1-1201 |
660 |
3P+1NC |
||||||||
|
LC1-1810 |
660 |
32 |
18 |
4 |
7.5 |
9 |
9 |
9 |
3P+1NO |
|
|
LC1-1801 |
660 |
3P+1NC |
||||||||
|
LC1-2510 |
660 |
40 |
25 |
5.5 |
11 |
11 |
11 |
15 |
3P+1NO |
|
|
LC1-2501 |
660 |
3P+1NC |
||||||||
|
LC1-3210 |
660 |
50 |
32 |
7.5 |
15 |
15 |
15 |
18.5 |
3P+1NO |
|
|
LC1-3201 |
660 |
3P+1NC |
||||||||
|
LC1-4011 |
660 |
60 |
40 |
11 |
18.5 |
22 |
22 |
30 |
3P+NO+NC |
1with three screws 0r 35mm din rail |
|
LC1-5011 |
660 |
70 |
50 |
15 |
22 |
25 |
30 |
33 |
||
|
LC1-6511 |
660 |
80 |
65 |
18.5 |
30 |
37 |
37 |
37 |
||
|
LC1-8011 |
660 |
110 |
80 |
22 |
37 |
45 |
45 |
45 |
||
|
LC1-9511 |
660 |
125 |
95 |
25 |
45 |
45 |
45 |
45 |
||
