| Technical Parameter | |
| Working Voltage | AC220V±15% |
| Rated Frequency | 50Hz |
| Maximum output current | 32A |
| Maximum Output Voltage | 7kW |
| Protection Class | IP54 |
| Working Environment | -30~60℃，relative humidity≤90%RH |
| Start Charging Method | Swipe Card Charging, Plug and Play Charging, Code Scanning Charging |
| Installation | Wall mounted, Floor standing (with column) |
| Protection Function | Over-current protection, surge protection, short-circuit protection, leakage protection, under-voltage protection, over-voltage protection, ground continuity protection, relay overheating protection |
| Material | High quality cold rolled steel plate + surface treatment |
